Industrial Line 250
CBN44 Series
Powerbox
250W Single Output AC/DC Switch Mode Power Supply
- Datasheet
- Certificate TÜV
- CB certificate
- RoHS declaration
- DoC declaration
Datasheet
Approval & certification
Declaration
***Not for new design*** The Powerbox Industrial line product range is a family of high density power supplies intended for applications demanding extremely high performance on both reliability and electrical safety. The products utilize innovative technologies and offers both AC/DC and DC/DC conversion, offering a wide range of inputs and output combinations. The portfolio includes high density externals, open frames, enclosed, DIN-rail, and board mounted DC/DC converters.
Product features
Single output industrial power supplies
High efficiency
200-400W output at convection cooling
Compliant with EN55022 and FCC Class B
Active PFC to meet IEC61000-3-2 Class A and D
Protection against overvoltage, overcurrent and overtemperature
RoHS compliant
CBN44 Series models
| Model # | Input voltage AC | Input voltage DCnom (min-max) |
Output power | Outputs Vnom (min-max) | Outputs A max |
|---|---|---|---|---|---|
| CBN44031 | 110/230VAC | N/A | 250W | Output 1: 12 (12 to 12)VDC | Output 1: 20.84A |
| CBN44046 | 110/230VAC | N/A | 250W | Output 1: 24 (24 to 24)VDC | Output 1: 10.42A |
